• DELEM DA53T Touch Color CNC System
• DELEM DA58T Color 2D graphical CNC System
• DELEM DA66T Touch 2D graphical CNC System
• DELEM DA69T Touch 3D graphical CNC System

• CYBELEC CybTouch 8 PS 2D graphic CNC System
• CYBELEC CybTouch 12 PS 2D graphic CNC System
• CYBELEC CybTouch 15 PS 2D graphic CNC System
• CYBELEC VisiTouch 19 2D and 3D graphic CNC System

• ESA S630 2D graphic CNC System
• ESA S640 2D graphic CNC System
• ESA S650W 2D graphic CNC System
• ESA S660W CNC System
• ESA S675W CNC System

• 2-Axis CNC Back gauge with X,R-Axis
• 4-Axis CNC Back gauge with X,R,Z1,Z2-Axis
• 5-Axis CNC Back gauge with X,R,Z1,Z2,Delta X2-Axis
• 6-Axis CNC Back gauge with X1,X2,R1,R2,Z1,Z2-Axis

• Control, safety, and operator protection
• Increases productivity
• Continuous ram speed and stopping time surveillance
• If an obstruction is detected the machine is automatically stopped
• Easy to adjust after punch change

• Optimized construction according to each press brake model
• Automatic parameter calculation from press brake CNC control
• Width of CNC crowning 95 or 250 mm
• Wide range of use, ideal crowning for thin sheet metal work and heavy bending
• Self-locking double wedge system
• Can take high local loads
• Additional fine adjustment in every 300 mm
• Low-maintenance

• Manual upper tool clamping
• Wilson pneumatic clamping
• Wila hydraulic clamping system

A counterbid occurs when we bend a very large, heavy and thin plate. The overhang generates a torque that makes the sheet bend around the die edge under its own weight, as we can see in the drawing. The sheet lifter helps to avoid this type of damage, supporting the plate during the entire bending cycle.

Active Angle control is a highly accurate angle control process that calculates the spring back for each individual bend, then controls the bend depth with Live Angle Bending to achieve the correct angle.

To answer these custom press brake needs, ZFY provides innovative tool storage solutions dedicated to press brake standard & custom tooling: the Tool Station (modular tooling storage & changing system) and standard tooling cabinets.

ZFY promotes a friendly environmental policy, and as such, all our equipment features the Hybrid Eco Function. Our hybrid servo-drive positioning system provides accuracy at any position.

The Smart Tooling App is part of the WILA Smart Tooling Concept: from easy and fast data entry to simplified inventory management and Bluetooth synchronization with the press brake control.

• Critical Issue solving/hotfixes
• Phone support
• Perfective updates / new features in CAM & Tulus software
• Software updates by ZFY
• Access to our ZFY-organised expert teams with Workshops, Dialogs, and experience exchange programs

ZFY is committed to the development of sheet metal working machinery in the field of Industry 4.0 to drive innovation, the road is complex but never stops.
